High-speed five-axis, five-head drilling machine designed for the Daily Brush Series, ensuring precise, efficient, and consistent hole processing.
Model VM70-25A offers high stability, high production efficiency, a modular platform design, and fast module replacement. With a five-axis design, it can meet the tufting requirements of various types of brushes.
The human–machine touch screen control system is flexible and easy to operate.
Equipped with 3 drilling heads and 2 tufting heads, it can produce a wide range of brushes.
Tufting method: round wire.
The system can pre-store up to 1,000 brush programs, and creating new programs is also very simple.
The needles, bristle knives, and all machine components are standardized in design, making replacement and maintenance very convenient.
Capable of producing brushes with 1–2 colors.
Optional platforms:
● Platform capable of producing sloped vertical bristle angles.
● Platform capable of producing spherical toilet brushes and hemispherical dish brushes.
|
Model |
VM70-25A |
|
Axis |
5 |
|
Drilling(pcs) |
3 |
|
Tufting(pcs) |
2 |
|
Stroke(mm) |
70 |
|
Speed(tufts/min) |
≤1000 |
|
Station |
6 |
|
Filament length(mm) |
50-240 |
|
Holes diameter(mm) |
3.0-8.0 |
|
Voltage(V.Hz) |
380.50 |
|
Machine power(KW) |
4.6 |
|
Weight(kg) |
2120 |
|
Dimensions(mm) |
L-2780×W-1950×H-1980 |
Q 1: Is your company a factory or trade company?
A: We are a factory, we are engaged in this business for more than 30 years, we also have our own trade company in charge of overseas & domestic marketing affairs.
Q 2:Do you have any certification?
A: SGS, CE, ISO, etc.
Q 3: Can you guarantee your quality?
A: Of course. We are a large scale professional factory. More importantly, we put a high value on our reputation. Best quality is our principle all the time. You can be assured on our production completely. We can make business by Trade Assurance on Alibaba,com.
Q 4: What is the payment term?
A: The best way for both of us is 30% T/T deposit and 70% T/T balance payment before shipping, since we will test the machine before shipping. Of course, you can choose the way that you prefer more convenient payment term such as T/T, L/C, Western Union,
etc.
Q 5: How about after-sales service?
A:We can offer 12 months free warranty since the machinery arrived at your factory. We also offer spare parts or repair service to our customer anytime and anywhere, we will send our technician to your factory if necessary.
Q 6: How to reach our factory?
A: Our factory is located in Yangzhou city, Jiangsu province, China. It takes about 20 minutes from Yangzhou International Airport to our factory by car, and about 2 hours from Shanghai by train, and we will arrange our driver to pick you up at the airport or Yangzhou railway station anytime.
